Specifiche?

Model

DVR-A1008NR5

System

Main processor

Technical grade embedded microprocessor HI 3520DV400

Operating system

Embedded LINUX operating system

System resource

Multi-channel real-time recording synchronously,multi-channel real-time playback,

multi-channel multi-user network operation, USB back up.

Interface

Operation interface

16bit real color GUI interface support mouse operation

Display screen

1/4/8 screen (take analog channel as an example,other is base on the selected channel

mode)

Video

Video standard

PAL/NTSC

Image encode

H.265

Monitor quality

VGA & HDMI max 1080P

Preview capability

8*1080N?6 in 1??4*1080P(6 in 1)

Encode capability

4*1080P@18fps(6 in 1)?8*1080N@15fps(6 in 1)?

Decode capability

4*1080P@18fps(6 in 1)?8*1080N@15fps(6 in 1)?

Multi-mode video input

AHD/XVI/TVI/CVI/ANALOG?8*1080N(15FPS/CH) / 4*1080P(18FPS/CH)

HVR: 2*1080P?5IN1?+2*1080P?IP?Support Digital to analog conversion NVR: 16*1080P; 8*5M

Motion detection

Each channel can set 192?16*12?detection area;can set multi-level of flexibility (for

local analog channel only)

Audio

Audio compression

G711A

Bidirectional talk

Support

Record and playback

Record mode

Manual>alarm>motion detection>timing

Local playback

1-8ch playback synchronously (take local analog input for example, other is depended

on the selected channel mode)

Video search

Time?date?event?channel search

Storage and back up

Video storage

Local HDD ?Network

Back up mode

Network backup?USB portable HDD?USB imprint?SATA imprint
