Model
DVR-A1008NR5
System
Main processor
Technical grade embedded microprocessor HI 3520DV400
Operating system
Embedded LINUX operating system
System resource
Multi-channel real-time recording synchronously,multi-channel real-time playback,
multi-channel multi-user network operation, USB back up.
Interface
Operation interface
16bit real color GUI interface support mouse operation
Display screen
1/4/8 screen (take analog channel as an example,other is base on the selected channel
mode)
Video
Video standard
PAL/NTSC
Image encode
H.265
Monitor quality
VGA & HDMI max 1080P
Preview capability
8*1080N?6 in 1??4*1080P(6 in 1)
Encode capability
4*1080P@18fps(6 in 1)?8*1080N@15fps(6 in 1)?
Decode capability
Multi-mode video input
AHD/XVI/TVI/CVI/ANALOG?8*1080N(15FPS/CH) / 4*1080P(18FPS/CH)
HVR: 2*1080P?5IN1?+2*1080P?IP?Support Digital to analog conversion NVR: 16*1080P; 8*5M
Motion detection
Each channel can set 192?16*12?detection area;can set multi-level of flexibility (for
local analog channel only)
Audio
Audio compression
G711A
Bidirectional talk
Support
Record and playback
Record mode
Manual>alarm>motion detection>timing
Local playback
1-8ch playback synchronously (take local analog input for example, other is depended
on the selected channel mode)
Video search
Time?date?event?channel search
Storage and back up
Video storage
Local HDD ?Network
Back up mode
Network backup?USB portable HDD?USB imprint?SATA imprint
Video input
8CH BNC(1.0Vp-p,75Ω)
Video output
1CH VGA?1CH HDMI
Audio input/output
