| Chipset | |
| Cloud | XMeye |
| CPU | IMX307+HI3516EV200 1/3" SONY 2.4 Megapixel High-resolution CMOS Sensor |
| OS | Embedded LINUX RTOS ,dual core 32 bits DSP (TI Davinci DM368), hardware compression, watchdog,128M DDR2; |
| Function | |
| Focus | Manual Focus |
| Frequenza Fotogrammi Video | 3.0 Megapixel@25FPS |
| Funzione operativa | * Superior low-light performance both in VGA mode and HD mode,Support ABLC; * Support WEB Configuration,IE Surveillance; * Support Dual Stream; * Support OSD,Chroma,Brightness,Saturation,Electric Zoom Configuration; * Support real-time transmission,Center warning and picture pop-up linkage supported ( after motion detection and IO alarm); * Support DDNS,UPNP remote control;Support Onvif 2.0;Support IR-Cut Switch,Sensible infrared; Webserver |
| Giorno/Notte | IR cut filter with auto switch, IR sensor. |
| Modalità di Registrazione | NVR Local/Recording |
| Onvif | Support Onvif 2.0 |
| Protocollo | RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/TCP/SMTP |
| Riduzione del rumore | S/N Ratio>50dB |
| Hardware | |
| Account di sicurezza delle funzioni di sistema | Multi-user Classification Management |
| Light sensor | 1 IR lamp control interface , algorithm control IR lamp open and close Support linkage between photoresistance input sign, image, IR-Cut and IR lamp. |
| porte RJ45 | 1 RJ45 Ethernet interface, 10/100M adaptation |
| Interface | |
| Temperatura di Lavoro | -10° 55° |
| Umidità di Lavoro | 0%-90%RH,Without Condensation |
| Alimentazione | |
| Alimentazione | DC 12V/1A - Poe 48V |
| Corrente in Ingresso | 3.0W |
| Size | |
| Peso | 1000g |
| Scheda Tecnica | |
| Compressione Video | H265+ / H265 |
| Illuminazione minima | 1Lux-sec |
| Lente | 2.8-12mm Manual Zoom Lens |
| Risoluzione | 3 Megapixel 2 Megapixel 1 Megapixel selezionabili |
