ModelNo.

NEXT PTZ 4x

CameraType

IP Camera

System

Embedded RTOS design

Camera

Pixels Effettivi

2.0Mega Pixels

Main stream:1920*1080

Substream:704*576

Frames Rates

PAL:25fps

NTSC:30fps

Sensore Immagine

1/2.8"SONY Exmor IMX307 CMOSSensor

2.48megapixel resolution (2000H*1241V)

DSP

Dualcore 32-bitDSP

3516C

Min. Illumination

Color 0.01Lux/F1.2

B/W 0.001Lux/F1.2

Adjust Parameters

DWDR, BLC, DNR,AE,AGC, D&N,Mirror, Flip,etc.

Video

Compressione

1. H264Main profile

Stream

support dualstream,AVI format

Bit Rate

support 0.1 M ~ 8 Mpbs bitrate adjustable

Frame Rates

support 1~30 fps adjust

Audio

Ingressi e uscita

Audio non presente

Compressione

G.711compression,support two-wayaudio intercom,supportaudio andvideosynchronized outPuo'

PTZ

Pan/Tilt Range

Pan:0°~260°;Tilt:-5°~60°

Preset Point

256

Controllo manuale

Pan:0.5°~12°/s;Tilt:0.51°~12°/s

PresetTour

8lines

Pattern Scan

4 lines

Network

1 * RJ45,10/100M, Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP

ONVIF

Support (ONVIF2.0)

POE

Support (optional)

WIFI

N/A

Filtro IR cut

Set of double lightswitch IR-CUT filter

Lenti a bordo

Motorize ZoomAuto Focus Lens 5-50 (10x)

Illuminatori infrarossi

4 pcsArray IR Leds F12

Infrarossi

850 nm

Distanza illuminazione

More than 50M

Connettore I/O

1*DC Connector,1*RJ45(10/100M Network),1*BNCconnector (CVBS,Option)

Voltaggio operativo

DC12V

Power

IROn:1000mAmax., IROff:Less than400mA

Working Enviroment

-10°C~+60°C,10%~90%

Dimensioni

200*150*85mm compresa staffa

Peso

1.4kg
